Whirlpool W11523104 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11523104 replaces AP7213145.

Description

This wire harness routes power and signals between the appliance's control and components, restoring reliable electrical connections for consistent operation. Replaces a damaged, frayed, or burned harness to help eliminate intermittent power or control problems. What it does:

• Carries power and control signals between the main control and motors, switches, or sensors
• Replaces broken or shorted wiring that can cause intermittent operation or failed cycles
• Restores proper connector fit when pins or terminals are corroded or loose
• Helps prevent blown fuses or tripped breakers caused by shorted or damaged wires

What's included: One wire harness as shown Install notes:

• Disconnect power (unplug or shut off breaker) before servicing to avoid shock
• Inspect connectors and mating terminals for damage; replace if terminals are loose or burned
• Route and secure the harness per OEM routing to avoid pinching or chafing
