Whirlpool W11523105 Wire Harness (Complete Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11523105 replaces AP7187781, W10872688.

Description

This replacement wire harness restores factory electrical connections between the appliance control and components to help re-establish proper operation and signal routing. It's a direct-fit harness used where the original wiring is damaged or worn. What it does:

• Routes power and control signals between the control board and components.
• Replaces broken, frayed, or burnt wiring that can cause intermittent faults or component failure.
• Helps resolve symptoms such as no power to a component, intermittent operation, or blown fuses related to damaged wiring.
• Maintains correct connector fit and wire routing for reliable operation when installed correctly.

What's included: One wire harness assembly. Install notes:

• Disconnect power before starting and verify the appliance is de-energized.
• Compare the new harness to the old one and transfer any clips or brackets as needed; do not modify wires or connectors.
• Reconnect all plugs fully and secure harness routing to prevent contact with moving parts or heat sources.
