Whirlpool W11551368 Wire Harness (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11551368 replaces AP7033420, W11200746, W11177653, W10637660.

Description

This wire harness connects the appliance's control components to power and sensors, restoring reliable electrical communication and operation. It replaces a damaged or worn harness to help stop intermittent power, no-start, or control errors. What it does

• Routes power and signal between the control board and console, switches, or sensors.
• Replaces frayed, melted, or broken wiring that can cause intermittent operation or failure to start.
• Restores proper connector fit where loose or corroded terminals cause poor electrical contact.
• Helps eliminate control errors and erratic behavior caused by broken or shorted wires.

What's included

• One complete wire harness assembly as shown.

Install notes

• Always disconnect power (unplug or shut off breaker) before accessing internal wiring.
• Compare the new harness to the old one and transfer any mounting clips or tie straps as needed.
• Route wires away from heat sources and sharp edges; secure with original clips or cable ties.
• If terminals or connectors are damaged, replace the entire harness—do not splice or tape high-current wires.
