Whirlpool W11551372 Wire Harness (Multi-Connector) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11551372 replaces AP7020123, W10861655, W11229011, W10242409.

Description

This multi-connector wire harness routes power and signals between appliance components to restore reliable electrical connections. Replace a damaged harness to fix intermittent operation or loss of function caused by broken wires, melted insulation, or loose plugs. What it does:

• Carries power and control signals between the control board and connected components
• Re-establishes electrical continuity when wires are frayed, broken, or connectors are corroded
• Helps stop intermittent operation, component failures, or no-power symptoms tied to wiring faults
• Prevents arcing or shorts caused by damaged insulation or loose connections

What's included:

• One complete wire harness assembly as shown

Install notes:

• Disconnect all power (unplug or switch off breaker) before starting any repair
• Compare the new harness to the old one; route and secure wires the same way to avoid pinching
• Use care with connectors—align and seat plugs fully until they click
• If you see damage to surrounding components, inspect and replace those parts as needed
