Whirlpool W11556660 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11556660 replaces AP7213149.

Description

This wire harness routes electrical connections between key components, restoring reliable signal and power flow to the appliance. Replace a damaged harness to stop intermittent operation and reduce the risk of shorts or burned connectors. What it does:

• Reconnects power and control circuits between the control board and components
• Restores consistent electrical continuity to eliminate intermittent or failed operation
• Prevents arcing or shorting when cracked insulation or damaged terminals are present
• Helps resolve symptoms like no power to specific components, blown fuses, or erratic behavior

What's included: One wire harness as shown Install notes:

• Disconnect power before service to avoid shock or injury
• Inspect connectors and mounting points; replace if terminals are corroded or pins are damaged
• Route harness to match original routing and secure with existing clips or supports
