Whirlpool W11561436 Wire Harness (Harness Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Switch.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11561436 replaces AP7175868, W10868533, W10539913, W10889263.

Description

This genuine replacement wire harness connects and routes power and signal lines between appliance components, restoring reliable electrical communication for normal operation and control response. What it does:

• Replaces damaged or frayed wiring that can interrupt power or signals
• Restores reliable connections between controls, motors, and sensors
• Helps resolve intermittent operation, loss of certain functions, or failure to start when caused by wiring faults
• Provides factory-style connectors and routing for secure, vibration-resistant connections

What's included: One new wire harness Install notes:

• Disconnect power to the appliance before starting any repairs
• Handle connectors carefully; match connector shapes and colors to the original
• Route the harness as the OEM diagram specifies and secure with clips or ties to prevent chafing
