Whirlpool W11569161 Wire Harness (Main Electrical Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11569161 replaces AP7175931, W11183910.

Description

This wire harness routes power and signals between a dryer's control and its components to restore reliable electrical connections and proper operation. It replaces a damaged or broken harness to stop intermittent power, no-starts, or component failures. What it does:

• Connects control board, switches, heating element and sensors with factory wiring and terminals
• Restores power and signal paths when original wires are frayed, burned, or disconnected
• Stops intermittent operation, fault codes, or components that won't power on due to open/shorted wiring
• Provides correct connector types and lengths to match the OEM routing and connections

What's included:

• One complete wire harness as shown

Install notes:

• Disconnect all power before beginning service to avoid shock or injury
• Verify connectors match the original harness; route wires following factory clips and strain reliefs
• Inspect mating terminals and connectors for heat damage; replace any damaged components
