Whirlpool W11662348 Wire Harness (Main Connector Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11662348 replaces AP7211152, W11392896.

Description

This wire harness routes power and signals between appliance components to restore reliable electrical connections and operation. It replaces damaged or worn wiring that can cause intermittent power, control errors, or non-working circuits. What it does:

• Connects control boards, switches, sensors, and motors per the OEM wiring layout
• Restores lost or intermittent electrical continuity caused by frayed or broken wires
• Prevents shorts and unreliable operation when original harness insulation or terminals are compromised
• Supports normal appliance functions tied to the affected circuit (power, controls, sensors)

What's included:

• One complete wire harness assembly as shown

Install notes:

• Disconnect power (unplug or shut off breaker) before inspecting or replacing the harness
• Verify routing and connector orientation against the appliance wiring diagram before installing
• Avoid pinching wires; secure the harness with existing clips or ties to prevent chafing
• If corrosion or damage is found at connectors, clean or replace terminals as needed
