Whirlpool W11677726 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11677726 replaces AP7215482, W11238411.

Description

This replacement wire harness restores the electrical connections between the appliance's control and its components so circuits operate reliably. Use it when wiring is damaged, burnt, or causing intermittent electrical faults. What it does:

• Replaces the appliance's factory wiring that links control, switches, motors, heaters, and sensors.
• Restores lost or intermittent connections that can cause components to stop working or operate unpredictably.
• Provides factory-style connector ends and routed wiring to maintain proper component communication and safety.
• Helps eliminate issues caused by frayed, burned, or broken wires.

What's included: One wire harness. Install notes:

• Disconnect power before starting and verify the appliance is de-energized.
• Take photos of existing wiring and connector locations to ensure correct routing and reconnection.
• Route and secure the harness with the same clips/retainers; avoid pinching or contact with hot/moving parts.
