Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. Whirlpool also makes various appliance models for Sears / Kenmore.
Part Number W11690158 replaces AP7217199, W11336943.
The Harness-Wire Assembly is an OEM component specifically designed for Whirlpool dishwashers. This assembly consists of wiring harnesses that connect and transmit power to various electronic control boards and components inside the dishwasher.
Symptoms of a bad harness-wire assembly can include intermittent or complete failure of functions like dispensing, heating, draining, or the wash motor running due to open or damaged connections within the wiring.
Causes may involve normal wear and strain on wires from repeated use over time, moisture damage to insulation coatings on wires, or damage to connectors from improper installation or handling.
Causes of a bad harness-wire assembly include:
This OEM part is also compatible with some KitchenAid, Jenn-Air, Amana, and Kenmore models that utilize similar components.
