Whirlpool W11708428 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11708428 replaces AP7225230, W11305540.

Description

This wire harness routes power and signals between the appliance's control and components, restoring reliable electrical connections for proper operation. It replaces a damaged or worn harness to help stop intermittent power, controls not responding, or component failures. What it does:

• Connects control board, switches, and motors so signals and power reach the right components
• Restores lost or intermittent electrical paths caused by frayed, pinched, or corroded wires
• Helps eliminate symptoms like intermittent operation, controls that won't respond, or components that don't power on
• Provides factory-style connector ends and color-coded wiring for correct reconnection

What's included: One wire harness Install notes:

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Verify harness routing and connector orientation before disconnecting the old harness to ensure correct reinstallation
• Inspect mating connectors and terminals for damage or corrosion; replace if necessary
