Whirlpool 74011475 Oven Door Hinge, Single OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Hinge.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 74011475 replaces AP4100244, 1189022, 7106P143-60, AH2088772, EA2088772, PS2088772.

Description

This oven door hinge supports and guides the door through its range of motion so it opens smoothly and seals tightly when closed. Replacing a fatigued hinge restores proper door alignment and consistent oven performance. What it does:

• Provides spring-assisted tension to control door opening and closing
• Helps the door seal evenly against the gasket to retain heat
• Maintains correct stop positions to prevent slamming or over-travel
• Common symptoms: door won't close fully or pops open, drops/slams, sits crooked, heat escaping/long preheat

What's included:

• One door hinge assembly

Install notes:

• Disconnect power at the breaker; allow the oven to cool completely before servicing.
• Remove the door per your model's procedure (often open to the broil stop, engage hinge locks, then lift off).
• Use hinge locks/pins to control spring tension and prevent snap-back during removal/installation.
• Support the door to avoid damage; many replace both hinges together to keep tension balanced.
