Best Seller
Manufacturer Part

Whirlpool W10889233 Refrigerator Ice Maker Assembly OEM Part

Manufacturer's Part Number: W10889233
Genuine Whirlpool part
Appliance Compatibility Tool
$118.95
IN STOCK - SHIPS TOMORROW
Compare At:
$141.55
You Save:
$22.60

Secure and trusted checkout with

IN STOCK Less than 100 left
Ships Tomorrow Guaranteed

Order now and we'll ship it out Tomorrow

Over 94% of our orders are delivered in 2 days or less

Call us 1-877-477-7278
Need Help? Chat with a Pro

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Auger, Helix, Crusher and Refrigerator Ice Maker & Related.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10889233 replaces AP6030691, 4455908, PS11765709, W10795988.

Description

This refrigerator ice maker assembly automatically fills, freezes, and ejects ice cubes to keep your bin stocked. Replace it when the original unit stops producing ice, won't complete a harvest cycle, or leaks around the mold area.
  • Forms, freezes, and harvests ice automatically into the storage bin
  • Coordinates with the water valve and internal controls to manage fill and shut-off
  • Common signs of failure: no ice production; cubes not ejecting or jamming; misshapen or hollow cubes; water dripping/leaking near the icemaker; intermittent clicking
What's included: 1 icemaker assembly Install notes:
  • Disconnect power and shut off the water supply before servicing
  • Remove the ice bin; loosen mounting screws; unplug the wire harness; transfer any mounting hardware or shut-off arm from the old unit if needed
  • Align the fill cup with the water tube; secure the new assembly and reconnect the harness
  • Restore power and water; allow several hours and discard the first batches

Do-It-Yourself Stories from Customers like You

Total Satisfaction Rating
5.0
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Do-It-Yourself Rating
Very Easy
30-60 minutes
