Whirlpool 4175453 Igniter Top (Spark Electrode For Gas Cooktop) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Igniter.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 4175453 replaces AP3103050, 3181453, 3186575, 3178505, 3181448, 3181450, 3181451, 3181452, 3181469, 3200, 4169265, AH356929, EA356929, PS356929.

Description

This igniter top is the spark electrode that produces the spark to light a gas cooktop burner, restoring reliable ignition for safe cooking. It replaces the worn or damaged electrode that fails to spark or lights intermittently. What it does:

• Sends the spark to ignite the burner when the control is turned on.
• Commonly used when burners click but do not light or flame is slow to ignite.
• Helps stop continuous sparking caused by cracked or misaligned electrodes.
• Works with the burner cap and gas valve to ensure consistent ignition.

What's included:

• One igniter top (spark electrode) as shown

Install notes:

• Disconnect power and shut off gas supply before attempting replacement.
• Handle the ceramic insulation carefully to avoid cracking; inspect wiring and connectors for damage.
• Verify correct part number and fit with your appliance diagram before ordering.
