Whirlpool W11134296 Surface Ignitor (Single) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11134296 replaces AP6285436, W10779132.

Description

This surface ignitor sparks the burner on gas ranges so you can light cooktops quickly and reliably. It replaces a worn or damaged ignitor to restore normal ignition and consistent burner operation. What it does:

• Creates the spark needed to ignite the burner when a control is turned on
• Restores ignition when burners fail to light or produce weak/no sparks
• Stops intermittent ignition or continuous clicking caused by a faulty ignitor
• Works as the user-replaceable electrode for surface burner ignition systems

What's included:

• One surface ignitor

Install notes:

• Disconnect electrical power and shut off the gas supply before starting.
• Handle the ceramic electrode carefully; oils or cracks can cause failure—avoid touching the tip.
• Verify proper wire connection and secure mounting; test ignition after reassembly.
