Whirlpool W11033422 Interlock (Door Switch Bracket) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11033422 replaces AP6038824, W10358241, 4461682, 461968971512, PS11770344, WPW10358241.

Description

This interlock is the door switch bracket used in select microwaves. It aligns and supports the door-switch mechanism so the oven runs only when the door is fully closed, restoring safe, consistent door-sensing and start/stop performance.

• Holds and aligns the door switches and latch levers inside the cabinet
• Ensures the microwave stops when the door opens and runs only when fully closed
• Common fixes: won't start unless the door is pressed, stops when the door is moved, or shows a door-related door message
• Replaces cracked, warped, or loose interlock brackets that cause intermittent operation

What's included: 1 interlock Install notes:

• Disconnect power before servicing; microwaves contain high-voltage capacitors
• Access is typically behind the control panel; note each switch's orientation and wiring before transfer
• Transfer existing switches and hardware to the new bracket as configured for your model
• Use caution around sharp cabinet edges
