Whirlpool W11661848 Inverter Box (Drive Control Module) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11661848 replaces AP7212546, W11461108.

Description

This inverter box is the drive control module that manages variable motor speed and power delivery for the appliance, restoring proper motor operation and performance when the original module fails. What it does:

• Controls inverter-driven motor speed and torque for efficient operation
• Regulates power conversion between main board and motor assembly
• Helps resolve symptoms like intermittent motor operation, failure to start, or unusual motor noises associated with a faulty inverter module
• Works as the electrical interface between the motor and the appliance control system

What's included: One inverter box Install notes:

• Disconnect power before servicing to avoid shock or equipment damage
• Handle the module by its edges and avoid touching electrical contacts
• Follow OEM wiring and mounting locations; reinstall connectors securely
