Whirlpool W11676781 Inverter Box (Motor Control Module) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11676781 replaces AP7215445, W11461102.

Description

This inverter box is the motor control module that manages variable-speed motor operation, restoring proper drive performance and enabling normal cycle functions. Fits select Whirlpool electronic-drive appliances. What it does:

• Regulates power and speed to the appliance motor for smooth, variable-speed operation
• Replaces a failed inverter to help resolve motor non-response or intermittent run issues
• Can stop or reduce abnormal motor noise caused by faulty inverter electronics
• Clears drive-related error codes and restores normal cycle starts when faulty

What's included:

• One inverter box (motor control module)

Install notes:

• Disconnect power before servicing to avoid electrical shock
• Handle the module by its edges and avoid contact with circuit components or moisture
• Use original mounting hardware and route wiring as removed; verify secure connectors
• After installation, run a test cycle to ensure normal motor operation
