Frank C Sunset Beach , NC December 24, 2019 Appliance: Jenn-Air Electric Downdraft Surface Unit C201-C The burner switches were not controlling the burners correctly specifically the lo temps were too high the switch knobs were also worn 1) I installed 4 ea new Whirlpool 700855K switches. (The old switches had INF-240P-871 stamped on them. 700855K was the cross-referenced P/N.) The installation was easy. There is slight difference in the terminal arrangement: 1) the old switch has raised terminals whereas the new switch has recessed terminals (for safety), and 2) the terminal markings are slightly different: The old switch has L1/L2/P/H1/H2 (5 terminals). The new switch has L1/L2/P/HC/H1(Also five terminals. I saw where one poster said there were 6 terminals on the new switch vs 5 on the old. There are indeed 6 male spade terminals on the new switch, but the terminal for L1 has two spades jumped together; thus only one terminal for L1. Only one of the spades needs to be used.) The connection is as follows (old to new): L1 to L1, L2 to L2, P to P, H1 to HC, and H2 to H1. I advise to 'tighten' the connections by very slightly crimping the female spades before pushing onto the switch male terminals. This will make a better connection. If the females are in bad shape they should be renewed. Mine were all OK, so I crimped a little as mentioned. After completion all 4 switches control their respective burners correctly. 2) I also replaced the four knobs w/ Whirlpool P/N WPY700854. The old knobs' numbers had worn off. They fit OK but slightly loose; I put a turn or two of aluminum foil on the switch shafts to give a tighter fit. Then they were fine. All in all a pretty easy job, and well worth it. The burners all work fine now. Read More... 20 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Pliers, Screwdrivers, Socket Set
Attilia R Martinsville , NJ November 04, 2014 Appliance: Model JENN AIR Needed new knobs for stove top There were two different knob tpes. Searched your web site, asked some questions, got correct knobs. They were easily changed. Read More... 16 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes
Patrick F Stanwood , MI July 11, 2014 Appliance: Model UNKNOWN TOO OLD Numbers were worn off the knobs due to use and age Got new parts fro a 30 years old and it and they were a perfect fit and replacement . all the detail was original . Read More... 8 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes
Quinton H Noti , OR April 21, 2014 Appliance: Model JENN AIR ELECTRIC STOVE TOP C 1978 +- Needed new knobs for my 30+ year jennair electric stove top the numbers had worn off the dial from cleaning it I ordered two knobs, they arrived in a couple of days, I replaced the old knobs with the new ones. A perfect fit. Very satisfied with the speediest service for the correct parts. Thank you. Read More... 7 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Glenn N Cypress , CA May 08, 2017 Appliance: Jenn-Air Electric Downdraft Surface Unit C201-C Terminal block was broken Replaced terminal block and other cosmetic parts. Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
