Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. Whirlpool also makes various appliance models for Sears / Kenmore.
Part Number W11166856 replaces AP6284513, 4547434, PS12348045, W10683517.
The door lock motor and switch assembly is an OEM replacement part for Whirlpool electric and gas ranges. It contains the motor that controls the locking of the oven door along with the switch mechanism that detects when the door is properly shut.
Causes of a bad assembly can include failure of electronic components over time, faulty wiring connections, or damage to moving parts that inhibit proper locking functions.
Symptoms include:
This OEM Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore brand ranges.
