Whirlpool WPW10294102 Lid Lock (240V) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10294102 replaces AP6018926, W10294102, 4444289, PS11752230.

Description

This 240V lid lock is used on select top-load washers. It secures the lid during operation and relays a closed/locked signal to the control, restoring safe spin performance and preventing interruptions when the original latch fails.

• Locks the lid during spin/high-speed phases to prevent opening
• Sends lid-closed/locked status to the control so cycles can start and continue
• Typical symptoms: lid won't lock or unlock, washer won't start or spin, lid lock light blinks, cycle won't advance or stops mid-cycle
• May present intermittent clicking from the lock or require pressing down on the lid to start

What's included: Includes 1 lid lock assembly. Install notes:

• Disconnect power before servicing
• Access varies by model; typically remove the console/top to reach the lock on the cabinet/lid flange
• Transfer wiring connector and mounting screws; align the lock with the lid strike
• Reassemble and run a test or spin cycle to proper locking

Tech tip: Inspect the lid strike for wear or misalignment, as it can prevent the new lock from engaging.
