Whirlpool WPW10128606 Lint Duct Assembly (Lint Screen Housing) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10128606 replaces AP6015420, W10128606, 1449404, 8066168, PS11748698, W10119263, W10128607.

Description

This lint duct assembly forms the sealed air path between the lint screen and the blower. Replacing a damaged or leaking duct restores proper airflow and drying performance while helping keep lint contained within the filtration path.

• Directs air from the drum through the lint screen to the blower and exhaust
• Maintains a sealed passage to optimize airflow and drying efficiency
• Replace if cracked, warped, or loose, or if mounting tabs are broken
• Common symptoms: long dry times, weak exhaust airflow, lint inside the drum/cabinet, or visible damage/gaps

What's included: 1 lint duct assembly Install notes:

• Disconnect power and shut off gas supply before servicing
• Remove the lint screen and access panels as required by the model to reach the duct
• Note fastener locations; transfer any attached sensors, brackets, seals, and screws from the old duct to the new one
• Vacuum lint from the blower housing and vent path before reassembly; ensure the duct seats and seals evenly
