Whirlpool W11132207 Main Wire Harness (Wiring Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11132207 replaces AP6802700.

Description

This main wire harness routes power and control signals between the appliance's control board and components, restoring electrical connectivity so the unit operates reliably. It's a direct-replacement wiring assembly used where the factory harness is damaged. What it does

• Carries power from the control board to motors, sensors and switches so components receive the correct electrical connections.
• Restores circuit continuity when broken, frayed or burned wires cause intermittent operation or component failure.
• Commonly used when the appliance won't start, displays control errors, or individual components receive no power.
• Matches OEM connector ends and wire routing to maintain proper fit and function.

What's included

• One main wire harness assembly

Install notes

• Disconnect power (unplug or switch off breaker) before inspecting or replacing the harness.
• Document wire locations or take photos before disconnecting connectors to ensure correct reassembly.
• Route harness to avoid pinch points and sharp edges; secure with existing clips or ties.
• If connectors or board terminals are corroded or damaged, replace or repair them to ensure a reliable connection.
