Whirlpool W11628776 Main Wiring Harness (Control Console Lcc) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11628776 replaces AP7195570, W10914403.

Description

This main wiring harness connects the control console (LCC) to the appliance's electrical components, restoring reliable signal and power routing for controls. It replaces damaged or worn harnesses that cause intermittent or non-functioning controls. What it does:

• Routes power and control signals between the console LCC and internal components
• Restores lost or intermittent control functions caused by broken, frayed, or burned wires
• Prevents error codes or shutdowns from poor or corroded connector contacts
• Enables proper operation of buttons, displays, and control-driven features

What's included: One main wiring harness (control console LCC) as shown Install notes:

• Disconnect power to the appliance before beginning any work to avoid electrical shock
• Handle connectors carefully; align pins and push fully to ensure secure connections
• Route harness along existing clips and channels to prevent chafing or pinching
• Inspect mating connectors and control board for damage before final assembly
