Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number 12047001 replaces AP4009917, 401387, AH2004474, EA2004474, PS2004474.
Description
This auger motor drives the ice-dispensing auger inside the freezer door to move ice from the bin to the dispenser chute, restoring normal ice dispensing when the auger won't turn. Fits compatible Whirlpool freezer ice dispensers. What it does:
- Turns the auger shaft to push ice through the dispenser chute.
- Replaces a failed or seized dispenser motor that causes no ice to dispense.
- Stops abnormal noises or grinding from the dispenser when motor gears are worn.
- Helps restore normal dispense speed and responsiveness when the motor is intermittent.
What's included: One auger motor. Install notes:
- Disconnect power to the refrigerator before servicing to avoid shock or injury.
- Access may require removing the door panel, inner liner, or ice bin—follow your model's service manual.
- Inspect the auger shaft and gears for damage and replace any worn components to prevent repeat failure.
