Whirlpool WP63341 Spin Gear Pawl (Washer Transmission) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP63341 replaces AP6010161, 63341, 670561, PS11743338.

Description

This small internal lever fits the washer's transmission spin gear. It engages the gear so the basket can spin as designed. Replacing a worn pawl can restore consistent spin performance and help reduce ratcheting noises from the gearcase. What it does:

• Engages the transmission's spin gear to transmit power to the basket during the spin cycle
• Provides one-way locking to prevent the spin gear from slipping under load
• Common symptoms of failure: basket won't spin or spins intermittently; loud clicking/ratcheting from the gearcase; delayed or harsh engagement into spin

What's included:

• One spin gear pawl

Install notes:

• Unplug the washer and turn off water supply; wear gloves and eye protection
• Located inside the gearcase; the gearcase must be removed and opened to access the pawl
• Expect residual oil inside the gearcase—use a catch pan and reseal per service procedures
• Photograph the gear stack and parts orientation during disassembly to aid reassembly
