Whirlpool W11684591 Plug (Electrical Connector) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11684591 replaces AP7216918, W10567345.

Description

This electrical plug connects an appliance wiring harness to its mate, restoring a secure electrical connection to enable normal operation. Fits specific Whirlpool-designed connectors for targeted replacement when a connector is damaged or corroded. What it does

• Provides a secure mating point for a wiring harness to restore an interrupted circuit.
• Replaces cracked, melted, corroded, or loose connector ends that can cause intermittent power or component failures.
• Helps prevent arcing and poor contact that lead to overheating or erratic operation.
• Use when visual damage, burned contacts, or broken retaining features are found on the original plug.

What's included

• One replacement plug.

Install notes

• Disconnect power at the breaker or unplug the appliance before inspecting or replacing electrical connectors.
• Verify connector orientation and seating; ensure mating terminals are clean and undamaged before installation.
• Use proper crimping or soldering and insulation methods per OEM guidance; avoid exposed conductors.
