Whirlpool 22003903 Pump Terminal Shield (Terminal Cover) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 22003903 replaces AP4029178, 1000941, AH2021435, EA2021435, PS2021435.

Description

This pump terminal shield is a replacement terminal cover that protects motor wiring and terminals on the pump assembly. It helps keep connections insulated and reduces risk of shorting or contact damage during operation. What it does:

• Covers and insulates pump motor terminals to prevent accidental contact and arcing
• Helps protect terminals from debris and moisture that can cause corrosion or electrical faults
• Supports secure routing and positioning of terminal wires to reduce stress on connections
• Common symptom: visible or exposed pump terminals, burnt insulation, or intermittent motor operation

What's included:

• One pump terminal shield (single terminal cover), as shown

Install notes:

• Disconnect power to the appliance before accessing the pump and wiring
• Remove the pump or access panel to fit the shield over the motor terminals
• Ensure terminals are fully seated and wires routed so the shield snaps/locks into place securely
• If terminals or wiring are damaged, replace or repair those components before installing the shield
