Whirlpool W11098401 Start Relay (Compressor) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11098401 replaces AP6049800, W10482495, 4534362, PS12070855.

Description

Start relay that helps the compressor get the power boost it needs to start. Replacing a failing start relay can restore normal compressor starts and help stop humming, clicking, or loss-of-cooling symptoms. What it does:

• Supplies a momentary current to the compressor start winding to initiate motor start-up.
• Helps the compressor begin running smoothly; a failed relay can prevent the compressor from starting.
• Common symptoms this part can address: refrigerator not cooling, compressor humming but not starting, intermittent starting or clicking.
• Works with the compressor's start circuitry; replace when relay shows failure signs or as directed by diagnostics.

What's included: One start relay. Install notes:

• Disconnect power to the appliance before accessing the compressor or electrical components.
• Access typically requires removal of the rear service panel; handle terminals and wiring carefully to avoid bending or damage.
• Ensure secure electrical connections and proper seating on the compressor.
