Whirlpool W10319762 Heat Shield (Oven Cavity), 1 Piece OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Guard, Shield, Barrier.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10319762 replaces AP4568334, 1876873, AH3407889, EA3407889, PS3407889.

Description

This replacement heat shield protects the oven cavity and nearby components from extreme heat, helping prevent damage to wiring and surrounding parts for safer, more reliable oven operation. What it does:

• Deflects and dissipates radiant heat away from sensitive components and insulation
• Prevents heat-related damage to wiring, control housings, and nearby panels
• Helps maintain proper oven airflow and temperature distribution when installed correctly
• Common symptoms of a failed shield include scorched or melted insulation, visible warping, or a persistent burning smell

What's included:

• One heat shield

Install notes:

• Disconnect power (and gas, if applicable) before starting any repair
• Handle carefully—edges may be sharp; wear gloves and eye protection
• Inspect mounting tabs and fasteners and replace any damaged hardware
• If you discover additional damage (wiring, insulation, panels), replace those parts as needed
