Whirlpool W10896113 Tub Insulation Shield (Dishwasher) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10896113 replaces AP6034125, W10380479, W10885326, WPW10380479, 4455182, PS11765812, W10616873, W10796454, W10866979.

Description

This tub insulation shield mounts at the front/base of the dishwasher tub to cover and secure the sound-dampening insulation. It helps protect the insulation from splash and wear so the blanket stays in place for quieter operation. What it does:

• Covers and protects the tub's insulation from moisture and abrasion
• Helps keep insulation properly positioned for sound and thermal performance
• Direct replacement for a cracked, warped, or missing shield
• Typical symptoms: exposed or sagging insulation, louder operation, or difficulty fitting the toe panel

What's included:

• 1 tub insulation shield

Install notes:

• Disconnect power and shut off the water supply before servicing
• Remove the lower toe panel/kickplate to access the shield area
• Position insulation correctly, then install the shield using the existing mounting points/hardware
• Reinstall the toe panel and test for proper fit and operation
