Whirlpool WPW10511911 Snap Bushing (Door) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Hinge.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10511911 replaces AP6022508, W10511911, 4447921, PS11755841.

Description

This snap bushing installs in a door panel opening to protect and guide wiring or tubing that passes through. Replacing a worn or missing bushing helps prevent chafing and pinching, supporting smooth, reliable operation. What it does:

• Snaps into the door panel hole to create a smooth pass-through
• Shields wiring harness or tubing from sharp edges and vibration
• Helps prevent pinched wires, damaged insulation, or leaks due to abrasion
• Common signs include a cracked/missing bushing, chafed wiring/tubing at the door pass-through, or rubbing noises when opening/closing

What's included:

• 1 snap bushing

Install notes:

• Disconnect power; shut off water supply if applicable
• Depress the old bushing's locking tabs and remove from the door panel opening
• Route the harness/tubing through the new bushing; align and press until it snaps fully into place
• Verify nothing is pinched and restore power/water
