Whirlpool W11126047 Orifice Spud (Gas Burner), 1 Piece OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related and Range / Cooktop / Oven Gas Conv Kit.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11126047 replaces AP6261154, W10566083, 4545744, PS12114447.

Description

The orifice spud is the fixed jet that meters gas to a burner. Replacing a worn, clogged, or incorrect spud helps restore proper flame size, cleaner combustion, and reliable ignition on your gas cooking appliance.

• Precisely meters gas flow to the burner through a fixed opening
• Helps produce a stable blue flame and consistent heat
• If clogged, damaged, or wrong size, can cause weak/yellow flames, uneven heating, delayed ignition, or burners not lighting
• Supports correct operation when matched to the specified fuel type and burner rating

What's included: 1 orifice spud Install notes:

• Shut off gas supply and power before servicing
• Match the spud to the exact burner position and fuel type specified in your model documentation
• Thread the spud into the orifice holder/manifold with a wrench; do not overtighten
• Restore gas, then leak-test connections and verify proper flame characteristics
