Whirlpool WPW10418332 Sump & Motor Assembly (Dishwasher Circulation Pump) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10418332 replaces AP6021169, W10195599, W10328225, W10418331, W10418332, WPW10195599, WPW10328225, WPW10418331, 4446563, PS11754490.

Description

This dishwasher sump & motor assembly restores strong wash circulation and seals the tub floor. It moves water through the spray arms for reliable cleaning and replaces a cracked sump or failed wash motor in one step.

• Circulates wash water through spray arms; helps when dishes aren't getting clean or spray is weak
• Seals and channels water at the tub bottom to help stop leaks from the center area
• Restores correct wash flow when the motor hums, grinds, or won't run
• One-piece assembly replaces a damaged sump and failed circulation pump in a single repair

What's included: One preassembled sump and circulation pump assembly. Install notes:

• Disconnect power at the breaker and turn off the water supply before servicing
• Remove lower rack and spray arm; pull the dishwasher out as needed to access the bottom
• Disconnect wiring and hoses, release the sump locking mechanism, and seat the new gasket evenly before locking in place
• Reconnect, restore power/water, and run a short cycle to check for leaks and proper operation
