Whirlpool 74011241 Infinite Switch (Surface Burner Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Switch.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 74011241 replaces AP4100435, 1188814, 7450P014-60, AH2088566, EA2088566, PS2088566.

Description

This infinite switch controls the heat level of an electric cooktop surface burner, restoring variable temperature control for cooking. It replaces a failed or erratic burner control to help burners heat evenly and respond to the knob. What it does:

• Regulates current to a surface heating element so the burner cycles between power levels
• Restores adjustable heat when a burner stays on one setting, won't heat, or heats intermittently
• Replaces a worn or damaged control that causes inconsistent burner performance
• Works with the cooktop's control knob to provide stepped power levels for cooking

What's included:

• One infinite switch assembly

Install notes:

• Disconnect power to the appliance at the breaker before servicing
• Match this part to the existing switch by part number and terminal layout before installation
• Handle terminals and wiring carefully; secure connectors fully to prevent loose connections
