Whirlpool BT1243712 Switch, Overload (Compressor) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number BT1243712 replaces AP4126049, 108242, AH2109860, EA2109860, PS2109860.

Description

This compressor overload switch helps protect the compressor by interrupting power if the motor overheats or draws excessive current. It replaces a failed thermal overload to help restore normal compressor starting and operation. What it does:

• Acts as a thermal protector that opens the circuit when the compressor overheats or is overloaded
• Prevents compressor damage by cutting power during abnormal current draw or excessive temperature
• Commonly replaced when a refrigerator or freezer won't start or the compressor runs intermittently
• Works with the start device to allow proper compressor starting and cycling

What's included:

• 1 overload switch for the compressor

Install notes:

• Disconnect power to the appliance before accessing the compressor compartment
• Located on or near the compressor; access usually requires removing the rear service panel
• Handle terminals carefully and reattach wiring exactly as found; secure mounting is required for proper function
