Whirlpool WPW10268910 Water Level Pressure Switch (3-Terminal) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10268910 replaces AP6018166, W10268910, 4443522, PS11751468.

Description

This pressure switch senses drum water level and tells the washer control when to stop filling — helping prevent overfills and ensuring correct wash cycles. It's a direct-replacement electrical switch assembly used on compatible Whirlpool washers. What it does:

• Detects water/pressure inside the washer tub and signals the control board when the correct level is reached
• Stops the fill valve when the required water level is reached to prevent overfilling
• Can cause no-fill, overfill, or incorrect cycle behavior when faulty
• Works with the machine's control logic to enable proper agitation and drain timing

What's included:

• One water level pressure switch (3-terminal) as pictured

Install notes:

• Disconnect power and shut off the water supply before servicing
• Note hose routing and connector orientation before removal to ensure correct reassembly
• Gently remove and attach the small pressure hose to avoid kinking or damage to the diaphragm
