Whirlpool W10339228 Water Level Pressure Switch (Washer) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Switch.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10339228 replaces AP4568145, 1877807, 3366849, AH3408138, EA3408138, PS3408138.

Description

This water level pressure switch senses the tub's water level and tells the control when to stop filling and move to the next stage, helping prevent overfilling and ensuring consistent wash, rinse, and spin performance.

• Monitors air pressure from the tub's air dome to determine water level
• Signals the control/timer to open/close inlet valves and advance the cycle
• Enables agitation and spin only after the target level is reached
• Common failure symptoms: incorrect fill levels, won't advance from fill, pauses mid-cycle, or repeated fill/drain behavior

What's included: 1 water level pressure switch Install notes:

• Disconnect power before servicing; shut off water supply as a precaution
• Access the switch in the console/top area (location varies by model)
• Move the pressure hose and wire connector(s) to the new switch; secure all connections air-tight
• Inspect the pressure hose for kinks, clogs, or cracks and clear/replace if needed to avoid repeat issues

This part fixes the following symptoms

• Will not fill with water
