Whirlpool W10339250 Water Level Pressure Switch OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Switch.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10339250 replaces AP4568154, 1862825, 8577842, AH3408148, EA3408148, PS3408148, W10213206, W10339328.

Description

This water level pressure switch senses the tub's water level via air pressure and signals the control to stop filling at the correct point, helping the cycle advance properly and guarding against overfilling.

• Monitors water level through the pressure hose and reports to the control
• Shuts off inlet valves when the target level is reached
• Allows the cycle to proceed and spin only when the tub is sensed empty
• Common symptoms of a failed switch include overfilling or underfilling, long fill, stopping during fill, not advancing, or water-level error codes

What's included: 1 water level pressure switch Install notes:

• Disconnect power and turn off water supplies before servicing
• Access the console/control area; move the wire harness and pressure hose to the new switch and secure it in place
• Inspect the pressure hose for kinks, cracks, or moisture; clear or replace if damaged to ensure accurate sensing
• Ensure an airtight hose connection, then run a test fill to verify proper shutoff and operation
