Whirlpool W10414159 Water Level Pressure Switch (Pressure Sensor) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10414159 replaces AP5324987, 2118702, AH3503206, EA3503206, PS3503206.

Description

This water level pressure switch senses the washer's water height and tells the control when to stop filling. It restores correct fill control so cycles can fill, drain and spin based on the selected load. What it does:

• Monitors tub pressure to detect water level and signals the washer control.
• Prevents overfilling or underfilling when working correctly.
• Commonly replaces a switch that causes continuous filling, no fill, or incorrect spin/drain behavior.
• Works with the washer's air/pressure hose and wiring harness to report level changes.

What's included: One water level pressure switch. Install notes:

• Disconnect power and turn off the water supply before starting work.
• Inspect and replace the small pressure/air hose if cracked, kinked or blocked; ensure a snug hose connection.
• Handle the electrical connector and diaphragm gently; avoid bending or pinching components.
• After installation, run a test cycle to ensure correct fill levels and operation.
