Whirlpool WP4-35940-001 Thermostat OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Temperature Control, Cold Control.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP4-35940-001 replaces AP6009061, 4-35940-001, 14211474, 14220687, 1938882, 4356670, 4356773, 68001249, 68001451, 8210259, 8210276, PS11742204, R0131223, R9800521.

Description

This mechanical thermostat is the appliance's temperature control. It senses internal temperature and opens or closes its electrical contacts to cycle the system, helping the unit reach and maintain the setting you select for consistent performance.

• Regulates temperature by switching power to the cooling or heating circuit as needed
• Helps prevent overcooling/overheating and unstable temperatures
• Common symptoms: runs constantly or won't start, temperature too warm or too cold, short-cycling, no response to knob/setting changes
• Visual damage, burnt terminals, or a thermostat that fails continuity tests indicate replacement

What's included: 1 thermostat Installation notes:

• Disconnect power before servicing
• Document wire locations; transfer wires one at a time and secure all connections
• If your unit uses a sensing bulb/capillary, route and secure it exactly as original; do not kink or sharply bend it
• Verify correct mounting and smooth knob/shaft movement, then restore power and test
