Whirlpool W11690896 Thermistor Service Kit (Plastic) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Defrost Thermostat, Sensor.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11690896 replaces AP7217225, WP12791416, 12791416, W10203133.

Description

This thermistor service kit monitors internal refrigerator temperature and relays it to the control to regulate cooling. The plastic-housed sensor restores accurate readings and steadier temperatures when the original sensor is damaged, out of range, or intermittent.

• Senses compartment or evaporator temperature and sends a resistance signal to the control
• Helps the control manage compressor and fan operation for consistent cooling
• Common signs of a faulty sensor: temperatures too warm/too cold, long run times or short cycling, frost buildup, or thermistor/sensor error codes

What's included: One thermistor service kit with plastic housing. Installation notes:

• Disconnect power to the appliance before servicing
• Access the sensor location (often behind an interior panel or on the evaporator cover); remove the original sensor/holder
• Install the new sensor in the same position/orientation; route wires away from sharp edges and moving parts; ensure the plastic housing is fully seated
• Restore power and allow up to 24 hours for temperatures to stabilize
