Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Refrigerator Temperature Control, Cold Control.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number WP4317800 replaces AP6009213, 4317800, 1101161, 1101162, 1101163, 1107261, 1107263, 1107272, 1107335, 1107775, 1107776, 1114273, 1114292, 2018, 2160427, 2164524, 2177057, 482163, 482164, 530765, 531037, 531174, 531595, 531611, 531962, 531987, 547586, 547587, 547589, 547590, 945539, 945596, 945597, 946642, 946644, 978040, 978041, 987237, 987238, 987239, GC142, GC184, MC142, PS11742365.
Description
Cold control that regulates cooling cycles to maintain set temperatures in the fresh-food section. Replacing a failed control restores more consistent temperature control and helps prevent food spoilage. What it does:
- Controls compressor/cooling cycles based on the selected temperature setting to maintain cabinet temperature.
- Common symptoms: refrigerator running constantly, not cooling, or temperature cycling irregularly.
- Interfaces with the fridge control housing and wiring to open/close the cooling circuit as needed.
What's included: One cold control thermostat. Install notes:
- Disconnect power to the appliance before starting any repair.
- Access the control housing/panel to remove the old control; note wire locations or take a photo for correct reinstallation.
- Handle any attached sensor or capillary tube gently to avoid kinks or damage.
- After installation, restore power and the refrigerator reaches and holds the desired temperature.
