Whirlpool WP3406712 Timer (3-Cycle) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP3406712 replaces AP6008569, 3406712, 4433732, PS11741709.

Description

• Rotates through three preset cycle positions to start, run, and end timed operations
• Controls power to motors and valves during each cycle stage
• Commonly replaces timers that fail to advance, won't start cycles, or stop mid-cycle
• Works with the appliance's existing wiring harness and control panel connections

• One timer assembly

• Disconnect power before servicing to avoid electric shock
• Handle carefully to avoid bending terminals; match wire locations during reassembly
• Inspect mounting and dial alignment; secure timer before testing
• Test appliance through a full cycle after installation to ensure proper operation
