Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Refrigerator Defrost Timer, Adaptive Defrost Control.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number WP61003601 replaces AP6009997, 61003601, 4435132, 54113-12, 61001819, 61003079, 66128-5, PS11743172.
Description
This mechanical rotary defrost timer controls and advances the refrigerator's defrost cycle so the evaporator periodically melts frost buildup, helping restore normal cooling. It replaces a worn or stuck timer to return automatic defrost operation. What it does
- Advances the fridge's defrost cycle on a set schedule so the evaporator heats and melts frost
- Stops the compressor during defrost so frost is removed without cooling loss
- Common symptom: excessive frost buildup on evaporator or freezer compartment
- Common symptom: refrigerator or freezer runs constantly or does not cool properly
What's included
- One defrost timer (rotary)
Install notes
- Disconnect power to the appliance before starting any repair
- Locate timer (control panel, kick plate, or rear panel depending on model) and note original orientation before removal
- Remove mounting screws and electrical connector(s); install new timer in the same position and reconnect wiring
