Whirlpool WPW10135260 Timer Harness Assembly (Wiring Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10135260 replaces AP6015565, 4440889, PS11748846, W10135260.

Description

This timer harness assembly connects the appliance control timer to the oven's wiring, restoring reliable signal and power routing for timer-controlled functions. Fits as a direct replacement for worn or damaged timer wiring. What it does:

• Routes power and control signals between the appliance timer and internal components
• Replaces frayed, burnt, or disconnected wiring that can cause timer or control failures
• Helps stop intermittent timer operation, loss of timed functions, or no-response issues
• Matches OEM connector and wire routing for a correct electrical fit

What's included:

• One timer harness assembly as shown

Install notes:

• Disconnect power before servicing to avoid shock or injury
• Verify connector orientation and wire routing against the appliance harness path
• Inspect adjacent wiring and connectors; replace any damaged components for safety
