Whirlpool WPW10135271 Timer Harness Assembly (Wiring Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10135271 replaces AP6015567, W10135271.

Description

This timer harness assembly routes power and signals between the timer and other controls, restoring reliable timer operation. It replaces a worn or damaged timer wiring harness to help the appliance complete cycles correctly. What it does:

• Connects the timer to control circuits so cycle advances and timed functions operate
• Replaces frayed, cracked, or burnt wiring that can cause intermittent or no timer response
• Restores proper electrical connections that may cause the timer to fail or skip cycles
• Helps eliminate symptoms like no cycle advancement, intermittent timer operation, or error codes tied to timer circuits

What's included: One timer harness assembly. Install notes:

• Disconnect power (unplug or shut off breaker) before beginning work
• Observe connector orientation and routing; do not stretch or pinch wires during installation
• Inspect mating terminals and connectors for damage; replace if corroded or broken
