Whirlpool WPW10436302 Defrost Timer (Snap-In) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10436302 replaces AP6021392, W10436302, 4446791, PS11754716.

Description

This mechanical timer controls your refrigerator's automatic defrost cycle. Replacing a worn or stuck timer restores routine defrosting to prevent frost buildup and helps the appliance maintain steady, reliable cooling. What it does:

• Alternates power between the cooling circuit and the defrost heater at set intervals
• Helps clear frost from the evaporator so air can circulate properly
• Common failure symptoms: heavy frost on the back wall/evaporator, fresh-food section too warm, unit never defrosts or gets stuck in defrost, compressor running excessively

What's included:

• 1 defrost timer

Install notes:

• Disconnect power before servicing
• Access the timer (often in the control housing or rear service area); note wire positions with a photo
• Transfer wires one at a time to matching terminals and snap the timer into the bracket/original orientation
• Restore power and monitor through a cooling/defrost cycle to normal operation
