Whirlpool W10854240 Timer (Cycle Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10854240 replaces AP5999223, 4383816, PS11731277, W10642934.

Description

This Timer is the mechanical cycle controller for your appliance. It sequences power to components so cycles start, advance, and end at the proper times, helping restore dependable operation when the original timer wears or fails.

• Sequences power to motors, valves, and heaters according to the cycle selected at the timer shaft
• Advances the machine through each stage via a motor-driven cam and internal contacts
• Symptoms: cycle doesn't advance or stops mid-cycle
• Symptoms: appliance won't start or only starts intermittently
• Symptoms: runs past the end of the cycle or won't shut off

What's included: Timer assembly Install notes:

• Disconnect power before servicing; shut off water supply
• Photograph wiring and transfer wires to the same labeled terminals one at a time
• Reuse the original mounting hardware, dial, and knob
• After installation, run a short test cycle to ensure the timer advances properly
