Whirlpool W10247117 Transformer (Control Transformer), 1 OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10247117 replaces AP4411508, 1548979, AH2352752, EA2352752, PS2352752, W10134823, W10141184.

Description

• Steps down line voltage to the appliance's low-voltage control circuit so the control board and display receive stable power
• Enables proper operation of electronic controls, timers, and display backlights
• Common symptom: control panel unresponsive, blank or flickering display, or intermittent control operation
• Replacing a failed transformer can stop control-related resets or unpredictable behavior

• One control transformer

• Disconnect power at the breaker or unplug the appliance before beginning any repair
• Reference the appliance's tech sheet or wiring diagram for exact connector locations and mounting
• Keep all wiring connections tight and match original connector positions and polarity
